Walterscheid® Overrunning clutch EF 5/1R - 1114002

Product number: 1114002

EF5/1R KNP1 3/8-6H SPB8 KNP1 3/8-6HSPB10 GESCHL

Similar to illustration. Use products only for their intended use. Content is subject to change without notice. Further sizes and combinations may be available: contact us for availability. Cross references, designation of type by vehicle manufacturers or competitors are for guidance only. Check that the part is correct for the application before fitting.

Overrunning clutch with hole for spring type straight pin.
Overrunning clutches transmit torques in one direction only. They are often used for reversing operations, in order to prevent loading by rotating masses. As a rule, pivoting, spring-loaded keys engage grooves. The flanks of these grooves are designed in such a way that driving by the locking keys is only possible in one direction. Preferred applications include rotary mowers and flywheel drives, often in the form of a combined friction and overrunning clutch.

Product advantages

Easier coupling when the PTO shaft is braked
Protects against trailing masses

The scope of delivery includes a complete overrunning clutch EF5/1R.
