Walterscheid® PTO Driveshaft W 2400 - 1114332
W 2400 SC25U 360 K65/2 5511509 3510158+ZP40X36-20H/H
Similar to illustration. Use products only for their intended use. Content is subject to change without notice. Further sizes and combinations may be available: contact us for availability. Cross references, designation of type by vehicle manufacturers or competitors are for guidance only. Check that the part is correct for the application before fitting.
Standard drive shaft with connection forks
Product advantages
The W series PTO drive shaft offers tried-and-tested Walterscheid technology and is perfectly designed to suit all application areas. The excellent benefits of this Walterscheid PTO drive shaft is a long service life, ease of use, and great safety properties. For decades, Walterscheid has been a guarantee of the highest quality. The W series are optimally dimensioned for drivetrain tasks, from simple to complex ones. It impresses users with its robust design and high reliability for daily use. Another advantage: All of the components in the PTO drive shaft W series can be replaced really easily to increase ease of use or if spare parts are needed.
Product advantages
The W series PTO drive shaft offers tried-and-tested Walterscheid technology and is perfectly designed to suit all application areas. The excellent benefits of this Walterscheid PTO drive shaft is a long service life, ease of use, and great safety properties. For decades, Walterscheid has been a guarantee of the highest quality. The W series are optimally dimensioned for drivetrain tasks, from simple to complex ones. It impresses users with its robust design and high reliability for daily use. Another advantage: All of the components in the PTO drive shaft W series can be replaced really easily to increase ease of use or if spare parts are needed.
The scope of delivery includes a complete drive shaft size W2100 with connection forks (profile 30H8), guard, retaining chain(s), operating and assembly instructions incl. declaration of conformity.
- Type
- W
- Size
- 2400
- Shaft length (Lz)
- 360
- Item no. attachment WH-A
- 122710
- Item no. attachment WH-I
- 120134
- Torque of clutch in daNm
- 0
- Rotation speed max. RPM
- 540 UPM
- Form attachment WH-A
- RD30H8
- Form attachment WH-I
- RD30H8
- Cone Type WH-A
- RP9
- Protective colour
- Yellow
- SNR cone WH-I
- 365248
- Schutzrohrlänge-A
- 105.00
- Form Anschl.-WH-A
- RD30H8
- PR-Länge-A
- 180.00
- PR-Bef.
- AZ
- PR-Länge-I
- 210.00
- Kuppl./Freilauf
- K65/2
- Outer profile length
- 180
- Chain WH-A
- K
- Nipple shape/position
- 6B 6B
- SNR cone WH-A
- 365369
- PR-A
- ZNP40X36-20H
- KZ Anschl.-WH-A
- AGKF
- MD in daNm
- 0.00
- PR-I
- ZWP40X36-20H
- Length of guard tube (inner)
- 160
- Nipple form / position I/A
- 6B 6B
- SNR Anschl.-WH-A
- 122710
- W-Länge
- 360.00
- Form Anschl.-WH-I
- RD30H8
- SNR Anschl.-WH-I
- 120134
- KZ Anschl.-WH-I
- K-KF
- Drehzahl max.
- 540 UPM
- Cone type WH-I
- WW70
- Schutzrohrlänge-I
- 160.00
- Attachment type of profile
- AZ
- Length of guard tube (outer)
- 105
- Inner profile length
- 210
- Cross seal
- P-DICHTUNG
- Clutch / One-way type
- K65/2
- Abbreviation attachment WH-A
- AGKF
- Abbreviation attachment WH-I
- K-KF
- Profile tube - outer type
- ZNP40X36-20H
- Profile tube - inner type
- ZWP40X36-20H
- Guard type
- SC25U
