Walterscheid® PTO Driveshaft with one-sided wide angle joint WWE 2480 - 1691618
WWE 2480 SDF25/1SW 1410 358310 3510041BGA/2AG
Similar to illustration. Use products only for their intended use. Content is subject to change without notice. Further sizes and combinations may be available: contact us for availability. Cross references, designation of type by vehicle manufacturers or competitors are for guidance only. Check that the part is correct for the application before fitting.
The listing of this OEM article is for the purpose of identification only. It is not intended as a spare part until further notice!
Discontinued Model. Limited availability. Successor product: 1610153
Product advantages
The Walterscheid diamond has been a guarantee of quality and safety for decades.
You can rely on their good reputation. It meets your requirements.
Discontinued Model. Limited availability. Successor product: 1610153
Product advantages
The Walterscheid diamond has been a guarantee of quality and safety for decades.
You can rely on their good reputation. It meets your requirements.
All components are designed specifically for the device and performance and it is not allowed to exchange for components other than those prescribed by Walterscheid. Damaged or missing parts can only replace with original Walterscheid parts and retrofit them in accordance with regulations and after consultation with Walterscheid.
The assignment, assembly and use of this model requires a detailed preliminary examination by qualified personnel. It is imperative to check the existing facilities and all of the machinery and equipment for their suitability for attachment. In particular, the characteristic values (e.g. vertical and pulling loads or torques) and the geometries (e.g. dimensions, screw hole patterns, free spaces) must be observed. Depending on the existing equipment of the machine, this can result in the use or purchase of additional components. The content of operating instructions must be observed.
The assignment, assembly and use of this model requires a detailed preliminary examination by qualified personnel. It is imperative to check the existing facilities and all of the machinery and equipment for their suitability for attachment. In particular, the characteristic values (e.g. vertical and pulling loads or torques) and the geometries (e.g. dimensions, screw hole patterns, free spaces) must be observed. Depending on the existing equipment of the machine, this can result in the use or purchase of additional components. The content of operating instructions must be observed.
- Type
- WWE
- Size
- 2480
- Shaft length (Lz)
- 1410
- Item no. attachment WH-A
- 319208
- Item no. attachment WH-I
- 366786
- Torque of clutch in daNm
- 0
- Rotation speed max. RPM
- 540 UPM
- Form attachment WH-A
- KP1 3/8
- Form attachment WH-I
- KP1 3/8
- Schutzrohrlänge-A
- 1050.00
- KZ Anschl.-WH-I
- QSG
- PR-A
- 2AG
- Protective colour
- Black
- Schutzrohrlänge-I
- 1065.00
- Form Anschl.-WH-I
- KP1 3/8
- Form Anschl.-WH-A
- KP1 3/8
- Cone Type WH-A
- RP6
- Length of guard tube (inner)
- 1065
- Inner profile length
- 1180
- Chain WH-I
- K
- SNR cone WH-I
- 129948
- Chain WH-A
- K
- PR-Länge-I
- 1180.00
- Chain
- K
- Length of guard tube (outer)
- 1050
- PR-I
- 1BGA
- Drehzahl max.
- 540 UPM
- KZ Anschl.-WH-A
- AGKF
- Nipple shape/position
- LL LB
- SNR Anschl.-WH-I
- 366786
- Outer profile length
- 1160
- SNR cone WH-A
- 127136
- PR-Bef.
- AA
- PR-Länge-A
- 1160.00
- SNR Anschl.-WH-A
- 319208
- W-Länge
- 1410.00
- Cone type WH-I
- WW80
- MD in daNm
- 0.00
- Cross seal
- STANDARD
- Abbreviation attachment WH-I
- AGKF
- Profile tube - outer type
- 2AG
- Profile tube - inner type
- 1BGA
- Guard type
- SDF25/1
