Walterscheid® PTO Driveshaft with one-sided wide angle joint WWE 2480 - 1692584

The listing of this OEM article is for the purpose of identification only. It is not intended as a spare part until further notice!

Product number: 1692584

WWE 2480 SDF25/1U 1660 JF5/12R+K64/22R165TOL 5911043 358310 1BGA/2AG

Similar to illustration. Use products only for their intended use. Content is subject to change without notice. Further sizes and combinations may be available: contact us for availability. Cross references, designation of type by vehicle manufacturers or competitors are for guidance only. Check that the part is correct for the application before fitting.

Standard drive shaft with connecting fork, overload clutches and wide-angle joint on one side

Product advantages

The W series PTO drive shaft offers tried-and-tested Walterscheid technology and is perfectly designed to suit all application areas. The excellent benefits of this Walterscheid PTO drive shaft is a long service life, ease of use, and great safety properties. For decades, Walterscheid has been a guarantee of the highest quality. The W series are optimally dimensioned for drivetrain tasks, from simple to complex ones. It impresses users with its robust design and high reliability for daily use. Another advantage: All of the components in the PTO drive shaft W series can be replaced really easily to increase ease of use or if spare parts are needed.

The scope of delivery includes a complete drive shaft size WWE2480 with connection fork (profile 1 3/8" (6)), cam type cut out clutch K64/22R, overrunning clutch JF5/12R, guard, retaining chain(s), operating and assembly instructions incl. declaration of conformity.

All components are designed specifically for the device and performance and it is not allowed to exchange for components other than those prescribed by Walterscheid. Damaged or missing parts can only replace with original Walterscheid parts and retrofit them in accordance with regulations and after consultation with Walterscheid.
The assignment, assembly and use of this model requires a detailed preliminary examination by qualified personnel. It is imperative to check the existing facilities and all of the machinery and equipment for their suitability for attachment. In particular, the characteristic values (e.g. vertical and pulling loads or torques) and the geometries (e.g. dimensions, screw hole patterns, free spaces) must be observed. Depending on the existing equipment of the machine, this can result in the use or purchase of additional components. The content of operating instructions must be observed.

This design is suitable for non-axis-parallel use when the simple universal joint is mainly in the extended position and the wide-angle joint is to be angled. Depending on the application, it is recommended that the wide angle joint can be operated up to a maximum angle of 80°. A constant angle during continuous operation of max. 20° should not be exceeded.
